Chapter 3 118
3. Place the mainboard onto the chassis.
4. Replace the two (2) screws.
5. Replace the adhesive tabs to secure the Audio board cable to the mainboard.
Step Size Quantity Screw Type
Mainboard M2.5*4 1
