137 Chapter 3
Replacing the Touchscreen Board
1. Place the touchscreen board onto the chassis.
2. Replace the two (2) screws.
3. Connect the touchscreen board to mainboard cable.
Step Size Quantity Screw Type
Touchscreen
Control Board
M2.5*4 1
