Acer Z5700 Series User Manual

129 Chapter 3
Replacing the Inverter Board
1. Place the Inverter Board onto the chassis.
2. Replace the two (2) screws to secure the inverter board.
3. Connect the mainboard to inverter cable.
Step Size Quantity Screw Type
Inverter Board M2.5*3 2

Acer Z5700 Series Specifications

General

Screen Size	23 inches
Operating System	Windows 7 Home Premium
CPU	Intel Core i5
Memory	4GB DDR3
Storage	1TB HDD
Graphics	NVIDIA GeForce GT
Display	1920 x 1080
Weight	Not applicable (All-in-One Desktop)
Battery Life	Not applicable (All-in-One Desktop)

Summary

Chapter 1 System Specifications

System Features and Components Overview

Details on system components, features, and specifications.

Detailed Hardware Specifications

Comprehensive technical specifications for hardware components.

Chapter 2 System Utilities

BIOS Setup Utility Introduction

Introduction to the BIOS Setup Utility and its functions.

Navigating BIOS and CMOS Setup

Instructions on how to navigate through BIOS menus and CMOS setup.

BIOS Configuration Options

BIOS Security and Flash Utilities

BIOS Utilities: DOS and WinFlash

Chapter 3 Machine Disassembly and Replacement

Disassembly Preparation and Safety

Tools, precautions, and initial steps before disassembling the computer.

Disassembly Flowchart

Removing Key Components

Removing Core Internal Parts

Removing Display and Peripheral Boards

Removing Major Assemblies

Steps for removing CPU, mainboard, and LCD panel.

Chapter 4 Troubleshooting

Common Problems and Diagnosis

General guide for diagnosing and resolving common computer issues.

Optical Drive and Display Issues

POST Code Reference

System Stability and Connectivity Issues

Chapter 5 Jumper and Connector Locations

BIOS Recovery Procedure

Instructions for recovering the BIOS using a USB drive.

Chapter 6 FRU (Field Replaceable Unit) List

FRU List Overview and Diagrams
