Acer Z5700 Series User Manual

43 Chapter 3
Screw List
Step Screw Quantity
Stand Cover M2.5*4 2
Stand Hinge M4*6 Ni 4
Rear Cover M2.5*7 4
Audio Board M2.5*4 Ni 2
HDD M2.5*4 Ni 2
HDD Bracket M3*4 Ni 4
ODD M2.5*4 Ni 2
ODD Brackets M2*2.5 Ni 4
Inverter Board M2.5*4 Ni 2
Touchscreen Control Board M2.5*4 Ni 2
Mainboard Shielding M2.5*4 Ni 7
WLAN M2*3 1
TV Tuner Module M2.5*4 Ni 1
VGA Card M2.5*4 Ni 4
Fan M2.5*5 Ni 3
Mainboard M2.5*4 Ni 1
USB Board M2.5*4 Ni 2
IR Receiver M2*3 1
Frame M2.5*4 Ni 15
LCD Panel M3*4 4
Power Board M2.5*4 Ni 2
Camera M2*3 2
Antennas M1.7*4 2
Speakers M2.5*4.0-I(NYLOK)IRON 6
