Advantech ICR-2701 User Manual

ICR-2701
4. Technical Specifications
4.1 Basic Parameters
Router parameters
Temperature range Operating
Storage
-40
◦
C to +75
◦
C
-40
◦
C to +85
◦
C
Humidity Operating
Storage
5 to 95 % relative humidity non condensing
5 to 95 % relative humidity non condensing
Altitude Operating 2000 m / 70 kPa
Degree of protection IP30
Supply voltage 9 to 48 V DC
Battery for RTC CR1225
Consumption Idle
Average
Peak
1.4 W
1.5 W
5.3 W
Dimensions of device w/o clip 113,2 x 80,3 x 42 mm (metal box)
117 x 83,8 x 51,4 mm (plastic box)
DIN rail clip specification DIN 35 mm, EN 60715
Weight 230 g (metal box)
170 g (plastic box)
Interfaces ETH0
ETH1
USB
RJ-45 socket for 10/100 Mbps Ethernet
RJ-45 socket for 10/100 Mbps Ethernet
USB-A socket
Table 8: Basic Parameters
20
