Advantech ICR-3201 User Manual

ICR-3241
1.11 DIN Rail Mounting
The DIN rail clip is suitable for a DIN rail according to EN 60715 standards.
When mounting the DIN rail clip, tighten the screws with max. torque of 0.4 Nm.
To remove the router from the DIN rail it is necessary to lightly push down the router so
that the bottom part of the DIN rail clip hitched to the DIN rail get out of this rail and then fold
out the bottom part of the router away from the DIN rail.
Figure 11: Removing from the DIN rail
12
