ICR-3241
4.6 Technical Parameters of WiFi
WiFi
Antenna connector 2x R-SMA – 50 Ω (MU-MIMO)
Supported WiFi bands 2.412 to 2.462 GHz, 5.180 to 5.825 GHz
Standards IEEE: 802.11b, 802.11b+g, 802.11b+g+n, 802.11a,
802.11a+n, 802.11ac
2.4 GHz supported channels 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11
5 GHz supported channels 36, 40, 44, 48, 149, 153, 157, 161, 165
Type of device Access point, Station
Security – Standards WEP, WPA, WPA2, WPA3, 802.1X
Security – Encryption WEP, TKIP, AES
Security – EAP Types EAP–FAST, EAP–TLS, EAP–TTLS, PEAP–GTC, PEAP–
MSCHAPv2, PEAP–TLS, LEAP
AP maximum users Unlimited (WiFi module supports multi-role operation in
STA and AP).
Table 17: Technical parameters of WiFi
4.7 Parameters of Bluetooth
Bluetooth
Antenna WLAN and Bluetooth share same LNA and an-
tenna
Versions supported Bluetooth 2.1 + EDR and Bluetooth 4.2 (Bluetooth
Low Energy or BLE)
Frequency Range 2.4 to 2.4835 GHz
Bluetooth standards Bluetooth version 2.1 with Enhanced Data Rate
Bluetooth 4.2 (Bluetooth Low Energy or BLE)
Bluetooth Data Rates Supported 1, 2, 3 Mbps
Bluetooth Modulation GFSK@ 1 Mbps
Pi/4-DQPSK@ 2 Mbps
8-DPSK@ 3 Mbps
Encryption support AES
Table 18: Technical parameters of Bluetooth
28
