ICR-3241
2. Hardware Functionality
See Chapter 1.3 for the product hardware overwiew. Table 1 lists a short description of the
hardware, including the links to the chapters with a detailed description.
2.1 SIM Card Slots
Slots for two SIM cards are located on the router under a metal cover. It is necessary to
insert an activated SIM card, to work properly. If the PIN is required for the SIM, enter it in
the router’s web interface. The SIM cards may have different APNs (Access Point Names)
adjusted. The SIM card changing procedure is described below.
Type of SIM cards: Mini SIM (2FF) 25.0 x 15.0 x 0.76 mm.
Inserting the SIM card:
• Always disconnect the router from the power supply before handling the SIM card.
• Unscrew two screws on the SIM card cover and remove the cover.
• To remove an inserted SIM card, use the flat end of a spudger, or your fingernail,
press the SIM card slightly into its slot until you hear a click. After hearing this click,
release the card, and it will pop out of its slot.
• To insert a SIM card push card into the slot until it clicks into place.
• Place back the cover and fix it by two screws.
Figure 13: SIM Cards Insertion
14
