AR / 25.07.23 / Version 1 11

3 SPECIFICATIONS

3.1 ASSEMBLY OF AG MAXI

Practice workshop safety at all times!

CAUTION

Disconnect the battery before the assembly of the AG Maxi.

1) Ensure the AG Maxi is placed on the ground in a stable condition.

2) Ensure all guards are fitted correctly before use.

Disconnect battery terminals

as shown by the arrows.

Place the wheel onto the base frame of the machine

and then secure it by placing the washer and

external Circlip in the order shown.
