AG MAXI User Manual

AR / 25.07.23 / Version 1 21
5.5 CONVEYOR BELT TENSION
Disconnect the battery before any maintenance work occurs.
The tensioning nut shown, when tightened or
slackened, will alter the belt to the desired
amount. If the belt is slipping when fully
loaded, alter the nut position until the belt
will hold grip to the motor.
1) – Slacken nut A
2) – Alter tension bolt B
A
B
