INSTALLATION – cont.
Installation Wiring Connections
Duo & Quattro Systems Single Phase
Outdoor Unit
1
E
3
4
5
6
Neutral
Comp Active
RV Active
Fan Active
Power Supply to Outdoor Unit
N
L
E
240 Volt supply
1
E
3
4
5
6
1
E
3
4
5
6
8
9
8
9
Earth
Active
1
E
3
4
5
6
No need to
wire the outdoor
sensor wires !
Remove 3 Pin
Power plugs from
Indoor unit
Sys A
Sys B
Indoor Unit 1
Indoor Unit 2
4.7k
Ω
Resistor
5 Cores + Earth to each
indoor unit from outdoor
Page 8
