Airwell RC4 User Manual

DC VOLTAGE IN THERMISTORS
Temp
Volts
All other
DUO De-icer
Volts
Temp
Volts
All other
DUO De-icer
Volts
-20 4.554 24 2.555 4.6
-19 4.529 25 2.500 4.5
-18 4.502 26 2.445
-17 4.475 27 2.391
-16 4.446 28 2.338
-15 4.417 29 2.284
-14 4.386 30 2.232 4.02
-13 4.354 31 2.180
-12 4.322 32 2.128
-11 4.287 33 2.077
-10 4.252 7.65 34 2.027
-9 4.216 7.59 35 1.978 3.56
-8 4.178 7.52 36 1.929
-7 4.140 7.45 37 1.881
-6 4.100 7.38 38 1.834
-5 4.059 7.31 39 1.798
-4 4.017 7.23 40 1.742 3.14
-3 3.974 7.15 41 1.698
-2 3.930 7.07 42 1.654
-1 3.885 6.99 43 1.611
0 3.839 6.91 44 1.569
1 3.792 6.83 45 1.527 2.75
2 3.744 6.74 46 1.487
3 3.695 6.65 47 1.447
4 3.646 6.56 48 1.409
5 3.595 6.47 49 1.371
6 3.544 6.38 50 1.334 2.4
7 3.492 6.29 51 1.298
8 3.443 6.19 52 1.263
9 3.388 6.09 53 1.228
10 3.333 6.00 54 1.195
11 3.278 5.9 55 1.162 2.09
12 3.223 5.8 56 1.130
13 3.168 5.7 57 1.009
14 3.113 5.6 58 1.069
15 3.257 5.5 59 1.040
16 3.002 5.4 60 1.011
17 2.946 5.3 61 0.983
18 2.890 5.4 62 0.956
19 2.833 5.1 63 0.929
20 2.777 5 64 0.904
21 2.722 4.9 65 0.879
22 2.666 4.8 66 0.854
23 2.610 4.7 67 0.831
All Three Thermistors on the unit have the same resistance values and therefore
the same voltage readings, except for the “Duo de-icer volts,” the voltage reading
on the outdoor coil on the duo units fitted with a double de-icer or typhoon PCB.
Page 22
