Unit Model Wiring and Pipe sizes details.
MODEL
Pipe
Size
MAX
LGT Power Cable size
C/B
SIZE NUMBER OF SENSOR
HORIZ Supply to:- As Per AS3000 INTERCONNECT WIRING
/VERT (see note) CABLES
DUCTED
DS/GC16RCF 1/4"&1/2" 20/10 m INDOOR 2.5mm² 20a FIVE 1 PAIR
DS/GC18RCF 3/8"&5/8" 20/10 m INDOOR 2.5mm² 20a FIVE 1 PAIR
DS/GC24RCF 3/8"&5/8" 20/10 m INDOOR 2.5mm² 20a FIVE 1 PAIR
DS/GC28RCFA 3/8"&5/8" 20/10 m OUTDOOR 4.0mm² 25a SIX 1 PAIR
DS/GC30RCFA 3/8"&5/8" 25/10 m OUTDOOR 4.0mm² 32a SIX 1 PAIR
DS/GC48RCF 3/8"&3/4" 50/25 m OUTDOOR 6.0mm² (min) 40a SIX 1 PAIR
DS/GC48RCFX 3/8"&3/4" 50/25 m OUTDOOR 4.0mm² 20a SIX 1 PAIR
DS/GC55RCFX 1/2"&7/8" 50/25 m OUTDOOR 4.0mm² 32a SIX 1 PAIR
DS/GC65RCFX 1/2"&7/8" 50/25 m OUTDOOR 4.0mm² 32a SIX 1 PAIR
CASSETTE
K/GC12RCC 1/4"&1/2" 25/7 m INDOOR 2.5mm² 10a FIVE 1 PAIR
K/GC16RCC 1/4"&1/2" 25/7 m INDOOR 2.5mm² 10a FIVE 1 PAIR
K/GC18RCC 3/8"&5/8" 25/10 m INDOOR 2.5mm² 15a FIVE 1 PAIR
K/GC24RCC 3/8"&5/8" 25/10 m OUTDOOR 2.5mm² 20a SIX 1 PAIR
K/GC30RCFA 3/8"&5/8" 25/10 m OUTDOOR 4.0mm² 25a SIX 1 PAIR
K/GC45RCFX 3/8"&7/8" 50/20 m OUTDOOR 4.0mm² 25a SIX 1 PAIR
CONSOLE
SX/GC16RCC 1/4"&1/2" 25/7 m INDOOR 2.5mm² 15a FIVE 1 PAIR
SX/GC18RCC 3/8"&5/8" 25/10 m INDOOR 2.5mm² 15a FIVE 1 PAIR
SX/GC24RCC 3/8"&5/8" 25/10 m OUTDOOR 2.5mm² 20a SIX 1 PAIR
SX/GC30RCF 3/8"&5/8" 25/10 m OUTDOOR 4.0mm² 25a SIX 1 PAIR
HI-WALL
XLM/GCXLM9RCA 1/4"&3/8" 10/6 m INDOOR 2.5mm² 10a FIVE 1 PAIR
XLM/GCXLM12RCA 1/4"&1/2" 12/8 m INDOOR 2.5mm² 10a FIVE 1 PAIR
XLM/GCXLM14RCA 1/4"&1/2" 12/8 m INDOOR 2.5mm² 15a FIVE 1 PAIR
XLM/GCXLM17RCA 1/4"&1/2" 15/10 m INDOOR 2.5mm² 15a FIVE 1 PAIR
XLM/GCXLM24RCA 3/8"&5/8" 16/10 m INDOOR 2.5mm² 20a FIVE 1 PAIR
XLM/GCXLM30RCA 3/8"&5/8" 20/10 m INDOOR 4.0mm² 25a FIVE 1 PAIR
XLM/GCXLM36RCA 3/8"&3/4" 20/10 m OUTDOOR 4.0mm² 32a SIX 1 PAIR
INVERTER
XLM/GC9RCINV 1/4"&3/8" 12/6 m INDOOR 2.5mm² 10a FOUR N/R
XLM/GC11RCINV 1/4"&3/8" 12/6 m INDOOR 2.5mm² 15a FOUR N/R
DUO
DUO99RCA 1/4"&3/8" 10/6 m OUTDOOR 2.5mm² 20a 2 SETS OF 6 N/R
DUO912RCA 1/4"&3/8" 10/6 m OUTDOOR 4.0mm² 25a 2 SETS OF 6 N/R
1/4"&1/2" 12/6 m
DUO1212RCA 1/4"&1/2" 12/6 m OUTDOOR 4.0mm² 25a 2 SETS OF 6 N/R
DUO1414RCA 1/4"&1/2" 12/7 m OUTDOOR 4.0mm² 25a 2 SETS OF 6 N/R
DUO912RCA 1/4"&3/8" 12/7 m OUTDOOR 4.0mm² 25a 2 SETS OF 6 N/R
3/8"&5/8" 12/7 m
MULTI-FLOW
XLS/GCXLM9RC 1/4"&3/8" 12/6 m INDOOR 2.5mm² 10a FIVE 1 PAIR
XLS/GCXLM12RC 1/4"&1/2" 12/6 m INDOOR 2.5mm² 10a FIVE 1 PAIR
Notes 1. Refer AS3000 for details. Local Electrical codes overrule and apply always.
2. N/R. = Not required for this model - Combination.
COMMISSIONING
Page 9
