ALLEN & HEATH Xone:K2 User Manual

Allen & Heath 11 XONE:K2 User Guide
MIDI CHANNEL NUMBER
By default the MIDI Channel number is set to 15 to prevent control interaction with Xone DB series
mixers which default to channel 16.
To change the MIDI channel number on your XONE:K2, you must first enter setup mode.
Setup Mode
To enter setup mode, press and hold down the encoder [1] then power up by plugging the USB cable to
your PC/Mac, (or RJ45 lead if powered from X-LINK). The switch matrix LED’s will flash RED three
times to indicate that the K2 has entered setup mode.
The display will default as above, with Switch ‘A’ (the MIDI CHANNEL setup option) being
illuminated.
Press the setup encoder [1] to display the current MIDI channel number; see below.
1
Setting MIDI Channel Number
The channel number is represented by the number of illuminated switches; in
this case MIDI Channel 14.
To change the MIDI Channel number, rotate the Setup encoder.
Once the desired MIDI Channel Number has been chosen, press the Setup
Encoder [1] to store it and return to the setup mode.
Press the amber switch to exit setup mode and the switch matrix LED’s will
flash RED three times.

ALLEN & HEATH Xone:K2 Specifications

General

Sample rate	48 kHz
Channels quantity	4 channels
Digital sound processing	- bit
Headphone connectivity	6.3 mm
USB 2.0 ports quantity	1
DJ mixer	Yes
Product color	Black
Video capability	No

Weight and Dimensions

Depth	358 mm
Width	135 mm
Height	30 mm
Weight	1000 g
