Chapter 1 PowerMonitor 500 Unit Overview
Selecting Data to Display
Table 1 and Tabl e 2 provide a guide to navigation through the metering data
displays available on the front panel display. Row 1…Row 5 indicate the rows of
the display (see Figure 2 on page 13
).
Press for <2 seconds to cycle through the data that is displayed in Row 1
of the display.
Selected data for Row 1 remains displayed until is pressed.
Press for <2 seconds to cycle through the data that is displayed in Rows
2…5 of the display.
Selected data for Rows 2…5 displays momentarily and then returns to the default
display.
Use and to cycle through the max, instantaneous, and demand
(dmd) values.
Table 1 - Row 1 Data
Parameters123456789 10
Row 1 Total kWh
(+)
Total kVARh
(+)
Total kWh (-
)
Total kVARh
(-)
kWh (+)
part.
kVARh (+)
part.
kWh (-)
part.
kVARh (-)
part.
Run Hours
(99999999.99)
RTC
IMPORTANT
The appropriate data is displayed based on the configured system. For
example, for delta (3P) systems, individual line data is not displayed for line-
to-neutral voltage, VA, VAR, W, and power factor.
Table 2 - Rows 2…5 Data
Parameters Set01234567
Row 2 V LN Σ V LL Σ An Hz VA Σ VAR Σ W Σ PF Σ
Row 3 V L1 V L1-2 A L1 - VA L1 VAR L1 W L1 PF L1
Row 4 V L2 V L2-3 A L2 - VA L2 VAR L2 W L2 PF L2
Row 5 V L3 V L3-1 A L3 - VA L3 VAR L3 W L3 PF L3
