Rockwell Automation Publication 1420-UM001E-EN-P - March 2016 49
PowerMonitor 500 Unit Data Tables Appendix A
Data Tables
These tables detail each specific data table and its associated elements, such as
address, length, description, and format.
Product Information
In the data tables, the symbol is used to indicate 3-phase or system values.
The context determines whether the symbol indicates average (for example,
voltage) or total (for example, power) values.
Table 9 - Table Properties
CIP Assembly Instance 100
No. of Elements 10
Length in Words 10
Data Type UINT
Data Access Read Only
Table 10 - Product Information Data Table
Element Modbus
Address
Length
(words)
Description / Units Data
Format
Notes
1 300001 1 Base firmware revision UINT MSB: ASCII code for model (A = V2, B = V1)
LSB: numeric number for revision
2 300002 1 EtherNet/IP module firmware revision UINT MSB: ASCII code for model
LSB: numeric number for revision
3 300003 1 Analog output module firmware revision (if exists) UINT MSB: ASCII code for model
LSB: numeric number for revision
4 300033 1 Letter 1 (from SX)
Letter 2 (from SX)
UINT MSB: ASCII code
LSB: ASCII code
5 300034 1 Letter 3 (from SX)
Letter 4 (from SX)
UINT MSB: ASCII code
LSB: ASCII code
6 300035 1 Letter 5 (from SX)
Letter 6 (from SX)
UINT MSB: ASCII code
LSB: ASCII code
7 300036 1 Letter 7 (from SX)
Letter 8 (from SX)
UINT MSB: ASCII code
LSB: ASCII code
8 300037 1 Letter 9 (from SX)
Letter 10 (from SX)
UINT MSB: ASCII code
LSB: ASCII code
9 300038 1 Letter 11 (from SX)
Letter 12 (from SX)
UINT MSB: ASCII code
LSB: ASCII code
10 300039 1 Letter 13 (from SX) UINT MSB: ASCII code
