Rockwell Automation Publication 1420-UM001E-EN-P - March 2016 71

Technical Specifications Appendix B

Pulse output DIN43864, IEC62053-31

Approvals CE, cULus (E56639)

Connections Screw-type

Cable cross-section area Max 2.5 mm

(14 AWG)

Screw tightening torque: 0.4 N•m min/0.8 N•m max

Suggested screw tightening torque: 0.5 N•m

Housing DIN

Dimensions (WxHxD) Module holder: 96 x 96 x 50 mm

Digital and analog output modules: 89.5 x 63 x 16 mm

Serial and Ethernet Communication modules: 89.5 x 63 x 20 mm

Depth behind panel, max 81.7 mm

Material ABS, self-extinguishing: UL 94 V-0

Mounting Panel mounting

Pollution degree 2

Protection degree, front

(1)

IP65, UL Type 4x indoor (NEMA4x indoor), UL Type 12 (NEMA12), for use on flat surface of a Type 4X Indoor enclosure; for

use on flat surface of a Type 12 enclosure.

Protection degree, screw terminals IP20

Weight, approx 400 g (0.88 lb) (packing included)

(1) Use with 60 °C or 70 °C copper conductor. Maximum surrounding air temperature 40 °C. Install the device in a pollution degree 2 environment. Open Type Device. The terminals L1, L2, and L3 are acquired

by a circuit where devices or system, including filters or air gaps, are used to control overvoltages at the maximum rated impulse withstand voltage peak of 6.0 kV. Devices or system is evaluated by using

the requirements in the Standard for Transient Voltage Surge Suppressors, UL 1449. Tighten terminals to 0.79

N•m (7 lb•in). The sum of the internal power consumption of the assembled modules is not

be more than 5.3 W.

Table 42 - General Specifications

Attribute Value

Table 43 - Power Supply Specification

Attribute Value

Auxiliary power supply Nominal: 120/240V AC (50/60 Hz) or 120/240V DC

Range: 100…240V AC (48…62 Hz)

Power consumption 6VA

Table 44 - Isolation Between Inputs and Outputs (1 minute)

Measuring Inputs Relay Outputs Communication
