14 Kinetix 5700 DC-bus Power Supplies
Rockwell Automation Publication 2198-IN009B-EN-P - June 2015
Circuit Breaker/Fuse Specifications
The Kinetix 5700 power supplies use internal solid-state motor short-circuit protection and, when protected by suitable branch circuit protection, are
rated for use on a circuit that can deliver up to 200,000 A (fuses) and 65,000 A (circuit breakers). While circuit breakers offer some convenience, there are
limitations for their use. Circuit breakers do not handle high-current inrush as well as fuses. Make sure that the selected components are properly
coordinated and meet acceptable codes, which includes requirements for branch circuit protection. Evaluation of the short-circuit available current is
critical and must be kept below the short-circuit current rating of the circuit breaker.
IEC (non-UL) Applications (380…415V, 50 Hz)
UL Applications (440…480V, 60 Hz)
DC-bus Power Supply
Cat. No.
Input Requirements
DIN gG Fuses, 100 kA
Amps, max
Miniature CB, 15 kA
Cat. No.
Motor Protection CB, 65 kA
Cat. No.
Molded Case CB, 65 kA
Cat. No.
Voltage Phases
2198-P031
324…528V AC Three
16 1489-M3D250 140M-D8E-C25 140G-G6C3-C25
2198-P070 40 1492-SPM3D400 140M-F8E-C45 140G-G6C3-C50
2198-P141 75 1492-SPM3D630 140-CMN-6300 140G-G6C3-C90
2198-P208 110 – 140-CMN-9000 140G-G6C3-D12
DC-bus Power Supply
Cat. No.
Input Requirements UL Fuses,
200 kA, 600V, Class J
Amps, max
Voltage Phases
2198-P031
324…528V AC Three
LPJ-15SP
2198-P070 LPJ-40SP
2198-P141 LPJ-70SP
2198-P208 LPJ-100SP
