Allen-Bradley Kinetix 5700 Installation Instructions

Kinetix 5700 DC-bus Power Supplies 3
Rockwell Automation Publication 2198-IN009B-EN-P - June 2015
Catalog Number Explanation
This publication applies to the following Kinetix 5700 DC-bus power supplies.
DC-bus Power Supply Catalog Numbers
Before You Begin
Remove all packing material, wedges, and braces from within and around the components. After
unpacking, check the item nameplate catalog number against the purchase order.
Parts List
The DC-bus power supplies ship with the following:
• DC-bus end caps
• Wiring plug connector set for mains input power (IPD), 24V control input power (CP),
digital inputs (IOD), shunt power (RC), and contactor enable (CED)
• Wiring plug connector for shunt power (RC) connections installed on the drive
• These installation instructions, publication 2198-IN009
Remove the Grounding Screw in Select Power Configurations
Remove the grounding screw when using ungrounded, corner-grounded, and
impedance-grounded power configurations.
DC-bus Power Supply
Cat. No.
Module
Width
mm
Input Voltage
Continuous
Output Power
kW
Continuous
Output Current
A
DC
rms
2198-P031
55
324…528V rms,
three-phase
710.5
2198-P070 17 25.5
2198-P141
85
31 46.9
2198-P208 46 69.2
TIP
Replacement connector sets are also available. See the Kinetix Servo Drives Specifications
Technical Data, publication GMC-TD003
, for more information.
IMPORTANT
If you have grounded-wye power distribution, you do not need to remove the screw. Go to
Install the DC-bus Power Supply on page 5.
EMC performance can be affected if you remove the grounding screw.
