Publication 2711C-UM001I-EN-P - July 2014 95
Appendix A
Specifications
General Specifications
PanelView Component - 2711C-F2M, 2711C-K2M, 2711C-T3M, 2711C-K3M,
2711C-T4T, 2711C-T6M, 2711C-T6C, 2711C-T6T, 2711C-T10C
Attribute Value
Display type
C200
C300
C400
C600
C1000
Monochrome transflective STN passive matrix
Monochrome transflective FSTN passive matrix
Color transmissive TFT active matrix LCD
Monochrome transmissive FSTN passive matrix or
Color transmissive CSTN passive matrix or
Color transmissive TFT active matrix LCD
Color transmissive TFT active matrix LCD
Display size
C200
C300
C400
C600
C1000
2 in.
3 in.
4 in.
5.7 in.
10.4 in.
Display area
C200
C300
C400
C600
C1000
49 x 14 mm (1.93 x 0.55 in.)
67 x 33 mm (2.64 x 1.30 in.)
95.04 x 53.856 mm (3.742 x 2.12 in.)
115 x 86 mm (4.53 x 3.39 in.)
211 x 158 mm (8.31 x 6.22 in.)
Resolution (pixels)
C200
C300
C400
C600
C1000
122 x 32
128 x 64
480 x 272
320 x 240
640 x 480
Backlight
C200
C300
C600 and C1000
C400 and C600 (2711C-T6T)
50,000 hours life, min., backlight not replaceable
Yellow/Green status indicator
White status indicator
CCFL
40,000 hours life, min., backlight not replaceable
White LED
Operator input
C200
C300
C400
C600 and C1000
Function keys or combination function keys and numeric
keypad
Analog touch or combination function keys and numeric
keypad
Analog touch and function keys
Analog touch
