Rockwell Automation Publication 750-IN001O-EN-P - October 2014 161
Power Wiring Chapter 4
Floor Mount Frames 8…10
Power Wiring Options
The following table describes the cabling options available for each Floor Mount
Frames 8…10 drive enclosure. Refer to pages 70
…114 for conduit plate
dimensions.
O X
Adequate Spacing
Available conduit plates provide adequate
spacing for typical cabling.
Possible – Evaluation is Required
Available conduit plates must be
evaluated to determine if cabling will fit.
Not Possible – Insufficient Spacing
Conduit plates are not available for the
specified configuration.
Frame Enclosure Rating Enclosure Code Cabinet Layout
Top Entry/
Top Exit
Top Entry/
Bottom Exit
Bottom Entry/
Top Exit
Bottom Entry/
Bottom Exit
8 IP20, NEMA/UL Type 1 B 600 mm Drive Cabinet
X X O
L, P, W 800 mm Drive Cabinet
O O
B 600 mm Drive with Cabinet Options Bay
X O
L, P, W 800 mm Drive with Cabinet Options Bay
O
B 600 mm Drive with Wiring Bay
L, P, W 800 mm Drive with Wiring Bay
B 600 mm Drive with Cabinet Options and Wiring Bays
L, P, W 800 mm Drive with Cabinet Options Bay and Wiring Bays
IP54, NEMA Type 12 J, K, Y 800 mm Drive Cabinet
X X X
J, K, Y 800 mm Drive with Cabinet Options Bay
X O O
J, K, Y 800 mm Drive with Wiring Bay
J, K, Y 800 mm Drive with Cabinet Options Bay and Wiring Bays
9 IP20, NEMA/UL Type 1 B 600 mm Drive Cabinet
O O O
L, P, W 800 mm Drive Cabinet
B 600 mm Drive with Cabinet Options Bay
X
L, P, W 800 mm Drive with Cabinet Options Bay
B 600 mm Drive with Wiring Bay
L, P, W 800 mm Drive with Wiring Bay
B 600 mm Drive with Cabinet Options and Wiring Bays
L, P, W 800 mm Drive with Cabinet Options Bay and Wiring Bays
IP54, NEMA Type 12 J, K, Y 800 mm Drive Cabinet
X X X
J, K, Y 800 mm Drive with Cabinet Options Bay
O O
J, K, Y 800 mm Drive with Wiring Bay
J, K, Y 800 mm Drive with Cabinet Options Bay and Wiring Bays
10 IP20, NEMA/UL Type 1 B 600 mm Drive Cabinet
O O O
L, P, W 800 mm Drive Cabinet
O
IP54, NEMA Type 12 J, K, Y 800 mm Drive Cabinet
X X X
To Next Page
