PowerFlex 520-Series Adjustable Frequency AC Drive
PowerFlex 523 Control I/O Terminal Designations
No. Signal Default Description Parameter
R1 Relay N.O. Fault Normally open contact for output relay. t076
R2 Relay Common Fault Common for output relay. t081
R3 Relay N.C. Motor Running Normally closed contact for output relay. P045
01 Stop Coast Three wire stop. However, it functions as a stop under all input modes and cannot be disabled. P045, P046,
P048, P050,
A544, t062
02 DigIn TermBlk 02/
Start/Run FWD
Run FWD Used to initiate motion and also can be used as a programmable digital input. It can be programmed with t062 [DigIn
TermBlk 02] as three wire (Start/Dir with Stop) or two wire (Run FWD/Run REV) control. Current consumption is 6 mA.
t063
03 DigIn TermBlk 03/
Dir/Run REV
Run REV Used to initiate motion and also can be used as a programmable digital input. It can be programmed with t063 [DigIn
TermBlk 03] as three wire (Start/Dir with Stop) or two wire (Run FWD/Run REV) control. Current consumption is 6 mA.
t063
04 Digital Common – Return for digital I/O. Electrically isolated (along with the digital I/O) from the rest of the drive. –
05 DigIn TermBlk 05/
Pulse In
Preset Freq Program with t065 [DigIn TermBlk 05]. Also functions as a Pulse Train input for reference or speed feedback. The
maximum frequency is 100 kHz. Current consumption is 6 mA.
t065
06 DigIn TermBlk 06 Preset Freq Program with t066 [DigIn TermBlk 06]. Current consumption is 6 mA. t066
11 +24V DC – Referenced to Digital Common. Drive supplied power for digital inputs. Maximum output current is 100 mA. –
12 +10V DC – Referenced to Analog Common. Drive supplied power for 0...10V external potentiometer.
Maximum output current is 15 mA.
P047, P049
13 0-10V In
(1)
(1) Only one analog frequency source may be connected at a time. If more than one reference is connected at the same time, an undetermined frequency reference will result.
Not Active For external 0-10V (unipolar) input supply or potentiometer wiper.
Input impedance: Voltage source = 100 kW
Allowable potentiometer resistance range = 1...10 kW
P047, P049,
t062, t063,
t065, t066,
t093, A459,
A471
14 Analog Common – Return for the analog I/O. Electrically isolated (along with the analog I/O) from the rest of the drive. –
15 4-20mA In
(1)
Not Active For external 4-20 mA input supply.
Input impedance = 250 W
P047, P049,
t062, t063,
t065, t066,
A459, A471
C1 C1 – This terminal is tied to the RJ-45 port shield. Tie this terminal to a clean ground in order to improve noise immunity
when using external communication peripherals.
–
C2 C2 – This is the signal common for the communication signals. –
