PowerFlex 520-Series Adjustable Frequency AC Drive
Smart Start-Up with Basic Program Group Parameters
The PowerFlex 520-series drive is designed so that start-up is simple and efficient. The Basic Program group contains the
most commonly used parameters. See the PowerFlex 520-Series Adjustable Frequency AC Drive User Manual, publication
520-UM001
for detailed descriptions of the parameters listed here, as well as the full list of available parameters.
= Stop drive before changing this parameter.
= Parameter is specific to PowerFlex 525 drives only.
No. Parameter Min/Max Display/Options Default
P030 [Language] 1/15 1 = English
2 = Français
3 = Español
4 = Italiano
5 = Deutsch
6 = Reserved
7 = Português
8 = Reserved
9 = Reserved
10 = Reserved
11 = Reserved
12 = Polish
13 = Reserved
14 = Turkish
15 = Czech
1
Selects the language displayed.
Important: The setting takes effect after the drive is power cycled.
P031 [Motor NP Volts] 10V (for 200V Drives), 20V (for 400V Drives),
25V (for 600V Drives) / Drive Rated Volts
1V Based on Drive Rating
Sets the motor nameplate rated volts.
P032 [Motor NP Hertz] 15/500 Hz 0.1 A 60 Hz
Sets the motor nameplate rated frequency.
P033 [Motor OL Current] 0.0/(Drive Rated Amps x 2) 0.1 A Based on Drive Rating
Sets the motor nameplate overload current.
P034 [Motor NP FLA] 0.0/(Drive Rated Amps x 2) 0.1 A Drive Rated Amps
Sets the motor nameplate FLA.
P035 [Motor NP Poles] 2/40 1 4
Sets the number of poles in the motor.
P036 [Motor NP RPM] 0/24000 rpm 1 rpm 1750 rpm
Sets the rated nameplate rpm of motor.
P037 [Motor NP Power] 0.00/Drive Rated Power 0.01 kW Drive Rated Power
Sets the motor nameplate power. Used in PM regulator.
P038 [Voltage Class] 2/3 2 = “480V”
3 = “600V”
3
Sets the voltage class of 600V drives. Only applicable to 600V drives.
P039 [Torque Perf Mode] 0/3 0 = “V/Hz”
1 = “SVC”
2 = “Economize”
3 = “Vector”
(1)
1
Selects the motor control mode.
(1) Setting is specific to PowerFlex 525 drives only.
P040 [Autotune] 0/2 0 = “Ready/Idle”
1 = “Static Tune”
2 = “Rotate Tune”
0
Enables a static (not spinning) or dynamic (motor spinning) autotune.
P041 [Accel Time 1] 0.00/600.00 s 0.01 s 10.00 s
Sets the time for the drive to accel from 0 Hz to
[Maximum Freq].
P042 [Decel Time 1] 0.00/600.00 s 0.01 s 10.00 s
Sets the time for the drive to decel from [Maximum
Freq] to 0 Hz.
PF 525
To Next Page
