PowerFlex 700 Technical Data
32 20B-TD001F-EN-P
Power Ratings and Branch Circuit Protection
Single-Phase Power Ratings
208/240 Volt Single-Phase AC Input
380…480 Volt Single-Phase AC Input
600…690 Volt Single-Phase AC Input
240V Single-Phase AC Input 208V Single-Phase AC Input
Temp.
Drive Catalog
Number Frame
Hp
Rating
Input
Amps
Three-Phase Output
Drive Catalog
Number Frame
Hp
Rating
Input
Amps
Three-Phase Output
V AC Amps V AC Amps °C
20BB2P2 0 0.25 1.5 0-230 1.1 20BB2P2 0 0.25 1.7 0-200 1.3 25
20BB4P2 0 0.5 2.8 0-230 2.1 20BB4P2 0 0.5 3.2 0-200 2.4 25
20BB6P8 1 1 5.1 0-230 3.4 20BB6P8 1 1 5.9 0-200 3.9 25
20BB9P6 1 1.5 7.2 0-230 4.8 20BB9P6 1 1.5 8.3 0-200 5.5 25
20BB015 1 2.5 11.9 0-230 7.7 20BB015 1 2.5 13.6 0-200 8.8 25
20BB022 1 3.75 17.3 0-230 11 20BB022 1 3.75 19.9 0-200 12.7 25
20BB028 2 5 22.2 0-230 14 20BB028 2 5 25.7 0-200 16.1 25
20BB042 3 7.5 33.4 0-230 21 20BB042 3 7.5 38.5 0-200 24.2 25
20BB052 3 10 41.3 0-230 26 20BB052 3 10 44.6 0-200 28 25
20BB070 4 12.5 55.6 0-230 35 20BB070 4 12.5 62.3 0-200 39.1 25
20BB080 4 15 63.6 0-230 40 20BB080 4 15 73.3 0-200 46 25
20BB104 5 20 84.6 0-230 52 20BB104 5 20 97.9 0-200 60 25
20BB130 5 25 105.7 0-230 65 20BB130 5 25 106.1 0-200 65 25
20BB154 6 30 125.2 0-230 77 20BB154 6 30 144.4 0-200 88.5 25
20BB192 6 37.5 156.1 0-230 96 20BB192 6 37.5 180.3 0-200 110.5 25
20BB260 6 50 211.4 0-230 130 20BB260 6 50 212.1 0-200 130 25
480V Single-Phase AC Input 380…400V Single-Phase AC Input
Temp.
Drive Catalog
Number Frame
Hp
Rating
Input
Amps
Three-Phase Output
Drive Catalog
Number Frame
kW
Rating
Input
Amps
Three-Phase Output
V AC Amps V AC Amps °C
20BD1P1 0 0.25 0.7 0-460 0.6 20BC1P3 0 0.2 1 0-400 0.7 25
20BD2P1 0 0.5 1.4 0-460 1.1 20BC2P1 0 0.4 1.6 0-400 1.1 25
20BD3P4 0 1 2.3 0-460 1.7 20BC3P5 0 0.75 2.7 0-400 1.8 25
20BD5P0 0 1.5 3.4 0-460 2.5 20BC5P0 0 1.1 3.9 0-400 2.5 25
20BD8P0 0 2.5 6 0-460 4 20BC8P7 0 2 6.9 0-400 4.4 25
20BD011 0 3.75 8.2 0-460 5.5 20BC011 0 2.75 9.3 0-400 5.8 25
20BD014 1 5 10.9 0-460 7 20BC015 1 3.75 12.5 0-400 7.7 25
20BD022 1 7.5 17.3 0-460 11 20BC022 1 5.5 17.8 0-400 11 25
20BD027 2 10 21.4 0-460 13.5 20BC030 2 7.5 24.6 0-400 15 25
20BD034 2 12.5 27 0-460 17 20BC037 2 9.25 30.3 0-400 18.5 25
20BD040 3 15 31.8 0-460 20 20BC043 3 11 35.2 0-400 21.5 25
20BD052 3 20 41.3 0-460 26 20BC056 3 15 45.9 0-400 28 25
20BD065 3 25 51.6 0-460 32.5 20BC072 3 18.5 59.7 0-400 36 25
20BD077 4 30 62.6 0-460 38.5 20BC085 4 22.5 70.5 0-400 42.5 25
20BD096 5 37.5 78.1 0-460 48 20BC105 5 27.5 87 0-400 52.5 25
20BD125 5 50 101.6 0-460 62.5 20BC125 5 27.5 103.6 0-400 62.5 25
– – – – – – 20BC140 5 37.5 117.4 0-400 70 25
20BD156 6 62.5 126.8 0-460 78 20BC170 6 45 142.6 0-400 85 25
20BD180 6 75 146.4 0-460 90 20BC205 6 55 171.9 0-400 102.5 25
20BD248 6 100 201.6 0-460 124 20BC260 6 66 220.6 0-400 130 25
20BD292 7 125 237.4 0-460 146 20BC292 7 80 247.7 0-400 146 25
20BD325 7 125 264.3 0-460 162.5 20BC325 7 90 275.7 0-400 162.5 25
600V Single-Phase AC Input 690V Single-Phase AC Input
Temp.
Drive Catalog
Number Frame
Hp
Rating
Input
Amps
Three-Phase Output
Drive Catalog
Number Frame
kW
Rating
Input
Amps
Three-Phase Output
V AC Amps V AC Amps °C
20BE1P7 0 0.5 1.1 0-575 0.9 25
20BE2P7 0 1 1.8 0-575 1.4 25
20BE3P9 0 1.5 2.6 0-575 2 25
20BE6P1 0 2.5 4.6 0-575 3.1 25
20BE9P0 0 3.75 6.7 0-575 4.5 25
20BE011 1 5 8.5 0-575 5.5 25
20BE017 1 7.5 13.3 0-575 8.5 25
20BE022 2 10 17.5 0-575 11 25
20BE027 2 12.5 21.4 0-575 13.5 25
20BE032 3 15 25.4 0-575 16 25
20BE041 3 20 32.6 0-575 20.5 25
20BE052 3 25 41.3 0-575 26 20BF052 5 22.5 43.1 0-690 26 25
20BE062 4 30 50.4 0-575 31 20BF060 5 27.5 49.9 0-690 30 25
20BE077 5 37.5 62.6 0-575 38.5 20BF082 5 37.5 68.4 0-690 41 25
20BE099 5 50 80.5 0-575 49.5 20BF098 5 45 82 0-690 49 25
