Allen-Bradley PowerFlex 750 Series User Manual

Rockwell Automation Publication 750-UM003D-EN-P - March 2017 39
Chapter 4
ATEX Monitoring
This section describes the parameter 41 [ATEX Sts] bit functionality, the
ATEX faults and configuration errors, and how to restart the drive after an
over-temperature fault.
Parameter 41 [ATEX Sts]
Parameter 41 [ATEX Sts] appears in the 11-Series I/O file, Motor PTC group,
when the ATEX option module is installed.
This parameter provides the status of the ATEX thermal sensor. If an ATEX
fault occurs, the corresponding bits change. When the temperature falls below
the trip point, the bits change back to their original settings.
A descriptive fault message is displayed. The fault message can be retrieved
from the fault queue after you clear the fault message from the display.
Topic Page
Parameter 41 [ATEX Sts] 39
ATEX Fault Descriptions 40
ATEX Configuration Errors 40
Restart the Drive after an Over-temperature Fault 41
File Group
No. Display Name
Full Name
Description
Values
Read-write Data Type
11-Series I/O
Motor PTC
41 ATEX Sts
ATEX Status
RO
16-bit
Integer
This parameter is not latched and only displays the status of the ATEX thermal sensor. When an ATEX fault is present, the corresponding bit value is 1.
When motor temperature is within the optimal range, the bit value is 0.
This parameter is available only when an ATEX option module is installed.
Bit 0 “Thrmlsnsor OK” – Thermal sensor is Ok.
Bit 1 “Short Cirkt” – Short circuit fault that is detected by thermal sensor.
Bit 2 “Over Temp” – Over temperature fault that is detected by thermal sensor.
Bit 3 “Voltage Loss” – Voltage loss fault has taken place on ATEX board.
Bit 13 “Thermostat” – Thermostat input has been selected.
Bit 14 “PTC Selected” – PTC input has been selected.
Options
Reserved PTC Selected Thermostat Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Voltage Loss Over Temp Short Cirkt Thrmlsnsor OK
Default0000000000000000
Bit 1514131211109876543210
0 = Condition False
1 = Condition True
