13
use and maintenance Atlantic 500
1
4
6
7
8
9
10
5
2
3
11
12
13
KEY
1) Battery
2) Main fuse carrier
3) Passenger grab rail
4) Fuel tank
5) Fuel tank filler cap
6) Fuel tank filler cap flag
7) Front brake fluid reservoir
8) Ignition switch/steering lock/seat lock
9) Horn
10) Auxiliary fuse carrier
11) Right inspection cover
12) Passenger right footrest
13) Engine oil level / filler plug
