16
use and maintenance Atlantic 500
Description Function
ABS (Anti-Lock Braking System) (
) (where fitted). Anti-lock braking system check-up. Comes on in the event of a malfunction.
If the light comes on during normal engine operation, it means
that there is a failure in the anti-locking system.
Stop the engine immediately and contact an aprilia Official Dealer.
High Coolant temperature indicator (
) Indicates the approximate temperature of coolant in the engine. When the pointer begins to
move away from the “Min” level, the engine is warm enough to rride. The central portion of the
scale corresponds to normal running temperature range. If the pointer reaches the red area or
the warning light comes on, stop the engine and check coolant level, see page 29 (COOLANT).
Exceeding the maximum temperature allowed (red “Max” area
of the scale) may lead to severe engine damage.
Coolant high temperature light (
) It comes on when the coolant temperature pointer reaches the red area. Immediately stop the
engine and check coolant level, see page 29 (COOLANT).
Exceeding the max. temperature allowed for a long period
may lead to severe engine damage.
Low beam light (
) Comes on when the low beam is on.
Side stand light (
) Comes on when the side stand is down.
When the side stand is down, the warning light comes on and
engine starting is inhibited.
Electronic fuel injection control light (EFI) Comes on, for about three seconds, whenever the ignition switch is set to “
” with the engine
stopped, thus testing the injection system operation. The light must go out as soon as engine is fired.
If the light comes one during the normal engine operation, it
means that the fuel electronic injection system is not working
properly. Stop the engine immediately and contact an aprilia Official Dealer.
Rev counter Indicates the number of engine revolutions.
LCD multifunction display External temperature, max. speed, average speed, battery voltage, average fuel consumption
after the last “RESET”, chronometer and kilometers till next scheduled service are displayed.
See page 21 (LCD MULTIFUNCTION DISPLAY).
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
