17
ARRANGEMENT OF THE INSTRUMENTS
KEY Fig. 3
1) Left rear-view mirror
2) High beam signaller push button (
a)
3) Clutch lever
4) Cold start lever (
e)
5) Dimmer switch (
a - b)
6) Multifunction computer push button (LAP)
7) Horn push button (
f)
8) Direction indicator switch (
c)
9) Start push button (
r)
10) Headlight switch (
o - p - •)
(not provided in the
_ version)
11) Throttle grip
12) Front brake lever
13) Engine stop switch (
n - m)
14) Right rear-view mirror
15) Instruments and indicators
16) Ignition switch/steering lock (
n - m - s)
Fig. 3
