19
INSTRUMENTS AND INDICATORS TABLE
Remember: 1 mile = 1.6 km
1 km = 0.625 miles.
Description Function
Multifunction computer It indicates the water temperature, the battery voltage, the hour and
minutes and it makes it possible to clock and record the track lap
times.
Revolution counter It indicates the number of engine revolutions per minute.
Speedometer It indicates the driving speed.
Total kilometres odometer It indicates the total number of kilometres covered.
Trip odometer It indicates the partial number of kilometres covered.
Trip odometer control knob By rotating it clockwise, it is possible to set the trip odometer to zero.
Low fuel warning light g It comes on when the quantity of fuel left in the tank is about 3 l.
High beam warning light
a It comes on when the headlight is on "high beam" position.
Neutral indicator warning light q It comes on when the transmission is in neutral.
Direction indicator warning light c It blinks when the direction indicators are on.
Mixer oil reserve warning light LED j It comes on when the ignition switch is in position "n" and the start
push button “r“ is pressed, thus checking the proper functioning of
the LED. If the light LED does not come on during the starting, provide
for replacing the bulb.
If the warning light LED comes on and does not go out
after the start push button "
r" has been released, or
if it comes on during normal functioning, this means
that the mixer oil reserve is being used; in this case, top up
the mixer oil tank, (see “MIXER OIL TANK” - page 30).
a
c
