5-27

CYCLE PARTS

SCARABEO 500

Key:

1. Front right brake calliper

2. Front left brake calliper

3. Pads – set

4. Kit pins + clip

5. Bleeder

6. Bleeder cap

7. TCEI screw M8x35

8. Front brake line

9. Front calliper brake force distributor line

10. Delay valve

11. Flanged Hex.screw M6X35

12. Brake line from m. cylinder to brake force distributor

13. Drilled screw

14. Bleeder

15. Bleeder cap

16. Oil line screw

17. Washer 10X14X1.6

18. Pads – sets

19. Kit for calliper ovhl

20. Rear brake calliper

21. Rear calliper mount

22. Flanged Hex.screw M8X40

23. Rear calliper brake force distributor line

24. Oil line screw

25. Washer 10X14X1.6

26. Pads – set

27. Bleeder

28. Bleeder cap

29. Kit pins + clip

30. Flanged Hex.screw M8X50

31. Flanged Hex.screw M6X16

32. Flanged Hex.screw M6X25
