CYCLE PARTS

5 - 30

SCARABEO 500

5.5.3. REMOVING THE BRAKE FORCE DISTRIBUTION

• Remove the front cover, see (REMOVING THE

FRONT COVER).

• Loosen and remove the three screws securing the

immobilizer control unit.

• Move aside the immobilizer control unit keeping it

connected to the wiring.

• Drain the braking system.

• Loosen and remove the two screws (1) and bleed

valve (2), collect the gaskets.

NOTE Mark the brake lines to ensure correct position at

reassembly.

• Protect the three brake lines to avoid fluid leakage.

• Loosen and remove the two screws (3) securing the

brake force distributor.

• Remove the brake force distributor.

NOTE When reassembling, bleed the braking system, see

(BRAKING SYSTEM).
