CYCLE PARTS

5 - 34

SCARABEO 500

5.6.3. DRAINING OIL

NOTE Before performing the following operations, prepare a

container of suitable capacity.

• Set the sleeve in a vice.

WARNING

The slider and sleeve assembly is filled with oil:

do not turn it upside-down or excessively tilt it

during disassembly.

• Move down plug (1) until it is possible to remove

circlip (2).

• Remove circlip (2).

• Remove plug (1) complete with O-ring.

• Remove the spring (3) and allow a few seconds to

let oil drip from it.
