APRILIA SCARABEO 500 User Manual

CYCLE PARTS
5-9
SCARABEO 500
5.1.4. REMOVING THE HELMET COMPARTMENT
• Raise the seat.
• Loosen and remove the two battery cover screws.
• Remove the battery cover.
• Remove the tail guard, see (REMOVING THE TAIL
GUARD)
• Remove the seat, see (REMOVING THE SEAT)
• Disconnect the electrical connector.
• Disconnect the cable controlling opening of seat -
actuator.
• Slide out the starter relay.

APRILIA SCARABEO 500 Specifications

General

Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Single disc
Engine Type	Single-cylinder, 4-stroke
Transmission	CVT
Power	39 HP
Max Torque	42 Nm @ 5, 500 rpm
Wheelbase	1560 mm
