FUEL SYSTEM
3-5
SCARABEO 500
• Working on either side, loosen and remove the two
screws securing the front lower support crosspiece.
• Remove the crosspiece.
• Loosen and remove the tank front retaining screw.
• Loosen and remove the tank rear retaining screw.
• Detach the tank from the frame and remove it.

APRILIA SCARABEO 500 Specifications

General

Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Single disc
Engine Type	Single-cylinder, 4-stroke
Transmission	CVT
Power	39 HP
Max Torque	42 Nm @ 5, 500 rpm
Wheelbase	1560 mm
