APRILIA SCARABEO User Manual

04_44
04_45
Rear optical unit (04_44, 04_45)
In the rear light there are:
- one tail light/stop light bulb «1»;
- two rear turn indicator bulbs «2».
To replace the bulbs:
•
Remove the tail light glass «3» by undoing the four screws «4».
TAIL LIGHT / STOP LIGHT BULB
•
Press the bulb «1» slightly and turn it anticlockwise.
•
Take out the bulb from its fitting.
NOTE
INSERT THE BULB IN THE BULB HOLDER SO THAT THE TWO GUIDING PINS
COINCIDE WITH THEIR GUIDES ON THE BULB HOLDER.
•
Install a bulb of the same type adequately.
REAR TURN INDICATOR BULB
•
To take out the bulbs of the turn indicator, turn:
- the left bulb CLOCKWISE;
88
4 Maintenance

APRILIA SCARABEO Specifications

General

Transmission	Automatic CVT
Front Brake	Disc
Engine	Single-cylinder, 4-stroke
Displacement	125 cc
Cooling	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Rear Suspension	Hydraulic shock absorber
Rear Brake	Disc
