APRILIA SCARABEO User Manual

- the right bulb ANTICLOCKWISE.
NOTE
UPON REFITTING, PLACE THE FAIRING OF THE REAR LIGHT «3» CORRECTLY
INTO PLACE.
CAUTION
TIGHTEN THE SCREWS «4» CAREFULLY AND SLIGHTLY TO AVOID DAMAG-
ING THE TAIL LIGHT GLASS «3».
04_46
Number plate light (04_46)
To remove the bulb:
•
Unscrew and remove the screw "8".
•
Remove the license plate bulb support «9».
•
Remove and replace the bulb «10» with another of the same type.
89
4 Maintenance

APRILIA SCARABEO Specifications

General

Transmission	Automatic CVT
Front Brake	Disc
Engine	Single-cylinder, 4-stroke
Displacement	125 cc
Cooling	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Rear Suspension	Hydraulic shock absorber
Rear Brake	Disc
