BIOS SETUP UTILITY
Main
Advanced H/W Monitor Boot Security Exit
Overclocking may cause
damage to your CPU and
motherboard.
It should be done at
your own risk and
expense.
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
EZ Overclocking
Load CPU EZ OC Setting [Press Enter]
CPU Configuration
CPU Frequency (MHZ)
PCIE Frequency (MHz)
Overclock Mode
[200]
[100]
[Auto]
Spread Spectrum
Boot Failure Guard
Advanced Clock Calibration
CPU Active Core Control
Boot Failure Guard Count
[Auto]
[Enabled]
[3]
[Disabled]
[All Cores]
Processor Maximum Frequency
North Bridge Maximum Frequency
Processor Maximum Voltage
x31.5 6300 MHZ
x31.0 6200 MHZ
1.5500 V
Multiplier/Voltage Change
HT Bus Speed
[Auto]
[Auto]
3.33.3
3.33.3
3.3
OC TOC T
OC TOC T
OC T
weakweak
weakweak
weak
er Screener Screen
er Screener Screen
er Screen
In the OC Tweaker screen, you can set up overclocking features.
EZ Overclocking
Load CPU EZ OC Setting
You can use this option to load CPU EZ overclocking setting. Please note
that overclocing may cause damage to your CPU and motherboard. It
should be done at your own risk and expense.
CPU Configuration
Overclock Mode
Use this to select Overclock Mode. The default value is [Auto]. Configura-
tion options: [Auto], [CPU, PCIE, Sync.], [CPU, PCIE, Async.] and [Optimized].
CPU Frequency (MHz)
Use this option to adjust CPU frequency.
PCIE Frequency (MHz)
Use this option to adjust PCIE frequency.
Spread Spectrum
This item should always be [Auto] for better system stability.
Boot Failure Guard
Enable or disable the feature of Boot Failure Guard.
Boot Failure Guard Count
Enable or disable the feature of Boot Failure Guard Count.
Advanced Clock Calibration
This allows you to adjust Advanced Clock Calibration feature. The default
value is [Disabled]. Configuration options: [Disabled], [Auto], [All Cores] and
[Per Core]. If you select [All Cores], you will see the option “Value (All
Cores)”. Configuration options: [+12%] to [-12%]. If you select [Per Core],
you will see the options “Value (Core 0)”, “Value (Core 1)”, “Value (Core 2)
” and “Value (Core 3)”. Configuration options: [+12%] to [-12%].

ASROCK 970 Pro Specifications

General

Socket	AM3+
Chipset	AMD 970
Form Factor	ATX
Maximum Memory	32GB
PCI Express x16	2
PCI Express x1	2
PCI Slots	2
Audio Chipset	Realtek ALC892
Audio	7.1 CH HD Audio
LAN	Realtek RTL8111E
Memory Slots	4
Memory Standard	DDR3 2100(OC)
SATA 6Gb/s	6
RAID Support	RAID 0, RAID 1, RAID 10
USB 2.0 Ports	8 x USB 2.0 (4 rear, 4 front)
USB 3.0 Ports	2
