ASROCK 970 Pro User Manual

4242
4242
42
BIOS SETUP UTILITY
Configure Super IO Chipset
Allow BIOS to Select
SerialPortBase
Addresses.
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
Serial Port Address
Infrared Port Address
[3F8 / IRQ4]
[Disabled]
3.4.63.4.6
3.4.63.4.6
3.4.6
Super IO ConfigurationSuper IO Configuration
Super IO ConfigurationSuper IO Configuration
Super IO Configuration
Serial Port Address
Use this item to set the address for the onboard serial port or disable it.
Configuration options: [Disabled], [3F8 / IRQ4], [2F8 / IRQ3], [3E8 / IRQ4],
[2E8 / IRQ3].
Infrared Port Address
Use this item to set the address for the onboard infrared port or disable it.
Configuration options: [Disabled], [2F8 / IRQ3], and [2E8 / IRQ3].
