A58M-K specifications summary
APU AMD
®
FM2+ Socket for AMD
®
A-series/Athlon™ Series processors
AMD
®
Turbo Core Technology 3.0 support
Supports APU up to 4 cores
• Refertowww.asus.com for the AMD
®
APU support list.
Chipset AMD
®
A58 Bolton D2
Memory
2 x DDR3 DIMM, max. 32GB, DDR3 2400 (O.C.) / 2133 / 1866 / 1600 /
1333 MHz, non-ECC un-buffered memory
Dual-channel memory architecture
• Themaximum32GBmemorycapacitycanbesupportedwith16GBorabove
DIMMs. ASUS will update the memory QVL once the DIMMs are available in the
market.
• HyperDIMMsupportissubjecttothephysicalcharacteristicsofindividual
APUs.
• Refertowww.asus.com for the latest Memory QVL (Qualified Vendors List).
• Whenyouinstallatotalmemoryof4GBcapacityormore,Windows
®
32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows
®
32-bit operating
system.
Graphics Integrated AMD
®
Radeon™ R/ HD 8000 / 7000 Series Graphics in the
A-Series APU
Multi-VGA output support: DVI and VGA ports
Supports Dual-link DVI with max. resolution 2560x1600@60Hz
Supports VGA with max. resolution 1920x1600@60Hz
AMD
®
Dual Graphics technology support*
Maximum shared memory of 2G
Supports AMD
®
Dual Graphics technology
• Refertohttp://www.amd.com/us/products/technologies/dual-graphics/Pages/
dual-graphics.aspx#3 for the discrete GPUs that support Dual Graphics technology.
Expansion slots 1 x PCIe 3.0/2.0 x16 slot*
1 x PCIe 2.0 x1 slot
1 x PCI slot
• OnlyFM2+processorssupportPCIe3.0.
Package contents
Check your motherboard package for the following items.
Motherboard ASUS A58M-K motherboard
Cables 2 x Serial ATA 3.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.

Asus A58M-K Specifications

General

Memory slots type	DIMM
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600, 1866, 2133, 2400 MHz
Processor socket	Socket FM2+
Processor manufacturer	AMD
Compatible processor series	AMD A
CPU fan connector	Yes
USB 2.0 connectors	2
Number of COM connectors	1
Number of SATA connectors	4
Number of SATA III connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	-
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	SATA II
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek 8111GR
Ethernet interface type	Gigabit Ethernet
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A58 FCH (Bolton D2)
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
BIOS type	UEFI AMI
ACPI version	4.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	183 mm
Width	226 mm
