Appendix B – Cables and Connectors 37
Maker Board UPS-EHL01 UP Squared V2
B.1 Cables and Connectors
This table provides detailed information about the cables and connectors used by the
UP Squared V2 (UPS-EHL01). If you have any questions about the configuration of your
board, please contact your AAEON sales representative.
Location
Connector
Function
Description
Mating Cable
PN/
CONN PN
Mating Cable Description
SW1
1601000990
PWR button
CN1
165300320Q
BIOS Prog
CN19
1655802020
FAN
CN2
1653530130
eDP
CN3
1655X00031
USB Header
170010015G
(TF)USB Cable.10P 1.0mm
Housing.USB A(F).15cm
CN4
165420753B
M.2 2280 M-Key
CN6
1652503109
Power Input
CN7
1654801832
USB 3.0
CN8
16530X0041
HAT 40
CN9
1654403931
DP/HDMI
CN10
1654207533
M.2 2230 E-Key
CN11
165300320Q
RS-232/422
170X000556
(TF)COM Port.2*3P to
D-SUB
9PP.Pitch=1.0mm.COM port
cable.100mm.FLYINGWAY.F
WAA-1529.for UPS-EHL01
CN12
1652828200
LAN
CN13
1654809302
USB 3.0
CN14
1655X00019
RTC
175011301K
(TF)Lithium
Battery.CR2032H.3V.240mA
H.w/cable 90mm.DIP.Battery
power.BP-CR2032-M90-001
CN15
1654907009
SATA
1709070500
(TF)SATA CABLE.7P Pitch
1.27mm.50cm
