Asus DSL-N14U User Manual

27
Using the USB application
The USB application menu displays several options including
AiDisk, Servers Center, and Network Printer Server.
Using AiDisk for File Sharing
AiDisk allows you to share files stored in a connected USB storage
device through the network.
Before using AiDisk, connect a USB storage device, such as a
USB hard disk or USB flash drive, to the USB 2.0 port on the rear
panel of your wireless router. The USB storage device should be
formatted and partitioned properly. Refer to the Plug-n-Share
Disk Support List for disk format, file and partition size at
http://event.asus.com/networks/disksupport
To avoid data loss or damage to the USB storage device, always
follow the steps to safely remove your USB device.
e8760_dsl-n14u_manual.indd 27 12/23/13 9:18:14 AM

Asus DSL-N14U Specifications

General

Flash memory	16 MB
Internal memory	64 MB
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Bandwidth	2.4 GHz
USB version	2.0
Input current	1 A
Rack mounting	-
xDSL connection	Yes
Dimensions (WxDxH)	123 x 190 x 35 mm
Maximum data transfer rate	300 Mbit/s
Compatible operating systems	Windows® 8.1 , 32bit/64bit\\r Windows® 8 , 32bit/64bit\\r Windows® 7 , 32bit/64bit\\r Windows® Vista , 32bit/64bit\\r Windows® XP , 32bit/64bit\\r Mac OS X\\r Linux
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Bundled software	ADSL Setting Wizards\\r Device Discovery\\r Firmware Restoration\\r Printer Setup Utility
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Security algorithms	128-bit WEP, 64-bit WEP, WPA2-PSK, WPS
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
LED indicators	DSL, LAN, Power, USB, WLAN
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	190 mm
Width	123 mm
Height	35 mm
Weight	314 g
