Asus DSL-N14U User Manual

43
5 Troubleshooting
If you encounter problems that are not mentioned in this
chapter, contact ASUS Technical Support.
Troubleshooting
IcannotaccesstherouterGUIforconguringtherouter.
• Delete the cookies and temporary files in your web browser. To
do this in Internet Explorer 8:
1. Launch your web browser, then click Tools > Internet
Options.
2.On the General tab, click Delete under Browsing history.
3.Tick Temporary Internet Files and Cookies. Click Delete.
Instructions for deleting cookies and temporary Internet files
vary with the web browser.
• Disable the proxy server settings, remove any dial-up
connections, and set the TCP/IP settings to obtain IP addresses
automatically. For more details, refer to the section Before you
proceed in this user manual.
Theclientcannotestablishawirelessconnectionwiththe
router.
Out of Range:
•Place the router closer to the wireless client.
•Change the channel settings.
e8760_dsl-n14u_manual.indd 43 12/23/13 9:18:20 AM

Asus DSL-N14U Specifications

General

Flash memory	16 MB
Internal memory	64 MB
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Bandwidth	2.4 GHz
USB version	2.0
Input current	1 A
Rack mounting	-
xDSL connection	Yes
Dimensions (WxDxH)	123 x 190 x 35 mm
Maximum data transfer rate	300 Mbit/s
Compatible operating systems	Windows® 8.1 , 32bit/64bit\\r Windows® 8 , 32bit/64bit\\r Windows® 7 , 32bit/64bit\\r Windows® Vista , 32bit/64bit\\r Windows® XP , 32bit/64bit\\r Mac OS X\\r Linux
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Bundled software	ADSL Setting Wizards\\r Device Discovery\\r Firmware Restoration\\r Printer Setup Utility
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Security algorithms	128-bit WEP, 64-bit WEP, WPA2-PSK, WPS
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
LED indicators	DSL, LAN, Power, USB, WLAN
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	190 mm
Width	123 mm
Height	35 mm
Weight	314 g
