Asus DSL-N14U User Manual

41
4 Using the utilities
• Install the wireless router's utilities from the bundled support
CD.
• If Autorun is disabled, run setup.exe from the root directory
of the support CD.
When you set the router to Access Point mode, you need to use
Device Discovery to get the router’s IP address.
Device Discovery
Device Discovery is an ASUS WLAN utility that detects any ASUS
wireless routers available on the wireless network and allows you
to configure the device.
To launch the Device Discovery utility:
Click Start > All Programs > ASUS Utility > DSL-N14U Wireless
Router > Device Discovery.
e8760_dsl-n14u_manual.indd 41 12/23/13 9:18:19 AM

Asus DSL-N14U Specifications

General

Flash memory	16 MB
Internal memory	64 MB
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Bandwidth	2.4 GHz
USB version	2.0
Input current	1 A
Rack mounting	-
xDSL connection	Yes
Dimensions (WxDxH)	123 x 190 x 35 mm
Maximum data transfer rate	300 Mbit/s
Compatible operating systems	Windows® 8.1 , 32bit/64bit\\r Windows® 8 , 32bit/64bit\\r Windows® 7 , 32bit/64bit\\r Windows® Vista , 32bit/64bit\\r Windows® XP , 32bit/64bit\\r Mac OS X\\r Linux
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Bundled software	ADSL Setting Wizards\\r Device Discovery\\r Firmware Restoration\\r Printer Setup Utility
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Security algorithms	128-bit WEP, 64-bit WEP, WPA2-PSK, WPS
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
LED indicators	DSL, LAN, Power, USB, WLAN
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	190 mm
Width	123 mm
Height	35 mm
Weight	314 g
