ASUS H170I-PRO
2-7
Menu bar
Menu items
Pop-up window
Quick note
2.2.2 Advanced Mode
The Advanced Mode provides advanced options for experienced end‑users to congure the
BIOS settings. The gure below shows an example of the Advanced Mode.
To access the EZ Mode, click Exit, then select ASUS EZ Mode or press <F7>.
Goes back
to EZ Mode
Language
MyFavorite
Q-Fan control
EZ Tuning Wizard
Hot Keys
Displays the CPU
temperature, CPU
and memory voltage
output
Sub-menu item
General help
Configuration fields
Scroll bar
Last modified
settings
Search on FAQs
