Asus K52JR User Manual

24 Notebook PC User Manual
Left Side
1
2
4
Kensington® Lock Port
Air Vents
The air vents allow cool air to enter and warm air to exit the
Notebook PC.
Ensure that paper, books, clothing, cables, or other objects do not
block any of the air vents or else overheating may occur.
Display (Monitor) Output
HDMI
HDMI Port
3
HDMI
3 4 5
6
21
HDMI
3 4 5 7 621
8 10 121192 5
14” model
15.6”/16” model
17.3” model

Asus K52JR Specifications

General

Graphics	ATI Mobility Radeon HD 5470
RAM	Up to 8GB DDR3
Chipset	Intel HM55
Optical Drive	DVD Super Multi
Camera	0.3MP
Networking	802.11 b/g/n
LAN	10/100/1000 Base T
Battery	6-cell Li-ion
Display	15.6" HD (1366x768)
Storage	320GB HDD
Card Reader	SD/MMC/MS/MS Pro
Interface	USB 2.0, VGA, HDMI, RJ-45
Audio	Built-in speaker and microphone
Dimensions	380 x 255 x 35.6 mm
Weight	2.62 kg
Operating System	Windows 7 Home Premium
Processor	Intel Core i3-350M / i5-430M / i7-620M
Power Adapter	90W
