Asus K52JR User Manual

Notebook PC User Manual 61
Fn+A (on selected models):
Toggles the light sensor ON and OFF
The built-in network cannot be installed later as an upgrade.
After purchase, network can be installed as an expansion card.
Connections
Network Connection
Connect a network cable, with RJ-45 connectors on each end, to the
modem/network port on the Notebook PC and the other end to a
hub or switch. For 100 BASE-TX / 1000 BASE-T speeds, your network
cable must be category 5 or better (not category 3) with twisted-pair
wiring. If you plan on running the interface at 100/1000Mbps, it must
be connected to a 100 BASE-TX / 1000 BASE-T hub (not a BASE-T4
hub). For 10Base-T, use category 3, 4, or 5 twisted-pair wiring. 10/100
Mbps Full-Duplex is supported on this Notebook PC but requires
connection to a network switching hub with “duplex” enabled. The
software default is to use the fastest setting so no user-intervention
is required.
1000BASE-T (or Gigabit) is only supported on selected models.

Asus K52JR Specifications

General

Graphics	ATI Mobility Radeon HD 5470
RAM	Up to 8GB DDR3
Chipset	Intel HM55
Optical Drive	DVD Super Multi
Camera	0.3MP
Networking	802.11 b/g/n
LAN	10/100/1000 Base T
Battery	6-cell Li-ion
Display	15.6" HD (1366x768)
Storage	320GB HDD
Card Reader	SD/MMC/MS/MS Pro
Interface	USB 2.0, VGA, HDMI, RJ-45
Audio	Built-in speaker and microphone
Dimensions	380 x 255 x 35.6 mm
Weight	2.62 kg
Operating System	Windows 7 Home Premium
Processor	Intel Core i3-350M / i5-430M / i7-620M
Power Adapter	90W
