30 Notebook PC User Manual
IMPORTANT! Never attempt to remove the battery pack while
the Notebook PC is turned ON, as this may result in the loss of
working data.
To install the battery pack:
Using Battery Power
The Notebook PC is designed to work with a removable battery pack.
The battery pack consists of a set of battery cells housed together.
A fully charged pack will provide several hours of battery life, which
can be further extended by using power management features
through the BIOS setup. Additional battery packs are optional and
can be purchased separately through a Notebook PC retailer.
Installing and Removing the Battery Pack
Your Notebook PC may or may not have its battery pack installed. If
your Notebook PC does not have its battery pack installed, use the
following procedures to install the battery pack.
1
2
3
1
3
2

Asus K52JR Specifications

General

Graphics	ATI Mobility Radeon HD 5470
RAM	Up to 8GB DDR3
Chipset	Intel HM55
Optical Drive	DVD Super Multi
Camera	0.3MP
Networking	802.11 b/g/n
LAN	10/100/1000 Base T
Battery	6-cell Li-ion
Display	15.6" HD (1366x768)
Storage	320GB HDD
Card Reader	SD/MMC/MS/MS Pro
Interface	USB 2.0, VGA, HDMI, RJ-45
Audio	Built-in speaker and microphone
Dimensions	380 x 255 x 35.6 mm
Weight	2.62 kg
Operating System	Windows 7 Home Premium
Processor	Intel Core i3-350M / i5-430M / i7-620M
Power Adapter	90W
