Asus K52JR User Manual

Notebook PC User Manual 43
Keyboard as a Numeric Keypad
The numeric keypad is embedded in the keyboard and consists
of 15 keys that make number intensive input more convenient.
These dual-purpose keys are labeled in orange on the key caps.
Numeric assignments are located at the upper right hand corner
of each key as shown in the figure. When the numeric keypad is
engaged by pressing [Fn][Ins/Num LK], the number lock LED lights
up. If an external keyboard is connected, pressing the [Ins/Num LK]
on the external keyboard enables/disables the NumLock on both
keyboards simultaneously.
To disable the numeric
keypad while keeping
the keypad on an external
keyboard activated, press the
[Fn][Ins/Num LK] keys on the
Notebook PC.
Keyboard as Pointers
The keyboard can be used as pointers while Number Lock is ON or
OFF in order to increase navigation ease while entering numeric
data in spreadsheets or similar applications.
With Number Lock OFF, press [Fn] and one of the pointer keys
shown below. For example [Fn][8] for up, [Fn][K] for down, [Fn][U] for
left, and [Fn][O] for right.
With Number Lock ON,
use [Shift] and one of the
pointer keys shown below.
For example [Shift][8] for up,
[Shift][K] for down, [Shift][U] for
left, and [Shift][O] for right.

Asus K52JR Specifications

General

Graphics	ATI Mobility Radeon HD 5470
RAM	Up to 8GB DDR3
Chipset	Intel HM55
Optical Drive	DVD Super Multi
Camera	0.3MP
Networking	802.11 b/g/n
LAN	10/100/1000 Base T
Battery	6-cell Li-ion
Display	15.6" HD (1366x768)
Storage	320GB HDD
Card Reader	SD/MMC/MS/MS Pro
Interface	USB 2.0, VGA, HDMI, RJ-45
Audio	Built-in speaker and microphone
Dimensions	380 x 255 x 35.6 mm
Weight	2.62 kg
Operating System	Windows 7 Home Premium
Processor	Intel Core i3-350M / i5-430M / i7-620M
Power Adapter	90W
