M2A-VM HDMI specications summary
(continued on the next page)
CPU Support AMD socket AM2 for AMD Athlon™ 64FX/
Athlon™ 64 X2/Athlon™ 64/Sempron processors
AMD64 architecture enables simultaneous 32-bit and
64-bit computing
Supports AMD Cool ‘n’ Quiet™ Technology
AMD Live!™ Ready
Chipset Northbridge: AMD 690G
Southbridge: ATI SB600
Front side bus 2000/1600 MT/s
Memory Dual-channel memory architecture 4 x 240-pin DIMM
sockets support up to 8 GB of unbufferred ECC/
non-ECC 800/667/533 MHz DDR2 memory modules
Expansion slots 1 x PCI Express™ x16 slot
1 x PCI Express™ x1 slot
2 x PCI slots
Graphics Integrated ATI Radeon X1250-based graphics
Supports Max. shared memory up to 256MB
Supports HDMI™ Technology with HDCP compliant with
max. resolution 1920 x 1080p
(The resolution cannot reach 1080p when playing HD
DVD and Blu-Ray Disc due to mainstream DVD player
limit)
Supports YPbPr component TV-out with max. resolutions
1280 x 720p and 1920 x 1080i
Supports DVI-D with max. resolution 2560 x 1600
(@60Hz)
Supports RGB with max. resolution 2048 x 1536
(@85Hz)
Dual VGA output support:
CRT & DVI/HDMI
DVI & HDMI
TV-out (YPbPr/AV/S) & DVI/HDMI
Note: Simultaneous output for YPbPr, AV, S, and RGB is
not supported.
Note: DVI-D can not be converted to output RGB signal
to CRT and isn’t compatible with DVI-I.
Storage ATI SB600 chipset supports:
- 1 x Ultra DMA 133/100/66/33 interface for two
(2) hard disk drives
- 4 x Serial ATA 3.0 Gb/s hard disk drives supporting
RAID 0, RAID 1 and RAID 10 conguration
High Denition Audio Realtek
®
ALC883 High Denition Audio 6-channel
CODEC
Supports Jack-Sensing, Enumeration and Jack-Retasking
technology
Supports S/PDIF out throught the port on the bundled
HDMI card

Asus M2A-VM HDMI Specifications

General

ECC	Yes
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Maximum number of SMP processors	1
USB 2.0 connectors	3
PS/2 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC883
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Bundled software	Drivers ASUS PC Probe II ASUS LiveUpdate Anti Virus (OEM)
Maximum graphics card memory	256 MB
Special features	ASUS MyLogo2 ASUS CrashFreeBIOS3 ASUS EZ Flash2 ASUS Q-Fan ASUS O.C Profile
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PXE, WOR by PME
Controller interface type	Serial ATA I/II
Controller 2nd interface type	UltraDMA 133/100
Networking features	Gigabit Ethernet
BIOS memory size	64 Mbit
RAID levels	0, 1

Weight and Dimensions

Depth	229 mm
Width	245 mm
