Asus M2A-VM HDMI User Manual

2-20 Chapter 2: BIOS setup
2.4 Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other
system devices.
Take caution when changing the settings of the Advanced menu items. Incorrect
eld values can cause the system to malfunction.
Phoenix-Award BIOS CMOS Setup Utility
Main Advanced Power Boot Tools Exit
Select Menu
Item Specic Help
Press [Enter] to set.
JumperFree Conguration
CPU Conguration
Chipset
PCIPnP
Onboard Device Conguration
USB Conguration
F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select SubMenu F10: Save and Exit
2.4.1 JumperFree Conguration
Select Menu
Item Specic Help
Set +1.2VNBSB Voltage
Phoenix-AwardBIOS CMOS Setup Utility
Advanced
JumperFree Conguration
+1.2VNBSB [Auto]
DDR2 Voltage Control [Auto]
CPU Voltage Control [Auto]
CPU Multiplier [Auto]
CPU Voltage [Auto]
CPU Frequency [200MHz]
+1.2VNBSB [Auto]
Allows you to set the +1.2VNBSB voltage.
Conguration options: [Auto] [+1.20V] [+1.30V] [+1.40V] [+1.50V]
DDR2 Voltage Control [Auto]
Allows you to set the operating DDR2 voltage.
Conguration options: [Auto] [+1.80V] [+1.90V] [+2.00V] [+2.10V]
CPU Voltage Control [Auto]
Allows you to set the operating CPU voltage.
Conguration options: [Auto] [100mV]

Asus M2A-VM HDMI Specifications

General

ECC	Yes
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Maximum number of SMP processors	1
USB 2.0 connectors	3
PS/2 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC883
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Bundled software	Drivers ASUS PC Probe II ASUS LiveUpdate Anti Virus (OEM)
Maximum graphics card memory	256 MB
Special features	ASUS MyLogo2 ASUS CrashFreeBIOS3 ASUS EZ Flash2 ASUS Q-Fan ASUS O.C Profile
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PXE, WOR by PME
Controller interface type	Serial ATA I/II
Controller 2nd interface type	UltraDMA 133/100
Networking features	Gigabit Ethernet
BIOS memory size	64 Mbit
RAID levels	0, 1

Weight and Dimensions

Depth	229 mm
Width	245 mm
